It can be used for joining 022Cr19Ni10 (SUS304L). It usually can be used for petroleum chemical industry, pressure vessel, food machinery, medical equipment, fertilizer equipment, textile machinery and so on.
Standard：AWS A5.22, E308LT1-1.It is 21%Cr-10%Ni austenitic stainless steel flux cored wire shielded by CO2.
Its carbon content is very low, the weld metal contains an appropriate amount of ferrite, and the crack sensitivity is low;
Soft and stable arc, less splash, beautiful forming, good slag removal, stable wire feeding, with excellent welding process performance.
It is mainly used in the fields such as etrochemical industry, food and medical treatment, ships, nuclear power and so on.
| Tensile Strength | 560MPa |
| Elongation | 42.5% |
| Brand | Size(mm) | Equivalent Specification | Welding Position | Type Of Current/Gas |
| AMH-308L | 1.2/1.6 | GB/T TS308L-FC11 | PA,PB,PC,PD,PE,PF | DC+/CO2 |
| AWS E308LT1-1 |
| Typical Chemical Composition Of Deposited Metal(wt%) | |||||||||
| C | Cr | Ni | Mo | Mn | Si | P | S | Cu | Others |
| 0.022 | 19.51 | 9.47 | 0.01 | 1.52 | 0.77 | 0.019 | 0.003 | 0.01 | - |
| Typical Mechanical Properties Of Deposited Metal | |||
| Y.P.(Mpa) | T.S.(Mpa) | E.L.(%) | I.V.(J) |
| - | 590 | 43 | - |
| Reference specification (DC+) | ||||
| Wire diameter（mm） | φ1.2mm | φ1.4mm | φ1.6mm | |
| Current range（A) | Flat welding | 100~260 | 110~300 | 120~320 |
| Vertical welding | 120~180 | 120~180 | 120~180 | |
| Horizontal position welding | 100~260 | 110~300 | 120~320 | |
