It can be used for joining 12Cr18Ni9（SUS302）or 06Cr18Ni10（SUS304). Therefore it usually can be used for petroleum chemical industry, pressure vessel, food machinery, medical equipment, fertilizer equipment, nuclear reactor and so on.
Standard：AWS A5.22, E308HT1-1.
It is 21%Cr-10%Ni austenitic stainless steel flux cored wire shielded by CO2.
Because it contains a certain amount of carbon, it is suitable for welding stainless steel equipment used at high temperature;
Soft and stable arc, less splash, beautiful forming, good slag removal, stable wire feeding, with excellent welding process performance.
Noted: 100%CO2(purity must be greater than 99.8%)
| Tensile Strength | 580MPa |
| Elongation | 38.5% |
| Brand | Size(mm) | Equivalent Specification | Welding Position | Type Of Current/Gas |
AMH-308H | 1.2/1.6 | GB/T TS308H-FC11 | PA,PB,PC,PD,PE,PF | DC+/CO2 |
| AWS E308HT1-1 |
| Typical Chemical Composition Of Deposited Metal(wt%) | |||||||||
| C | Cr | Ni | Mo | Mn | Si | P | S | Cu | Others |
| 0.049 | 19.5 | 9.69 | 0.02 | 1.4 | 0.71 | 0.026 | 0.003 | 0.02 | - |
| Typical Mechanical Properties Of Deposited Metal | |||
| Y.P.(Mpa) | T.S.(Mpa) | E.L.(%) | I.V.(J) |
| - | 605 | 41 | - |
